Product category: ABB Bailey INFI 90 Distributed Control System Power and Filter Subsystem

Product status: New and Original

Tariff code: 85371091

Product description:

ABB 086369-001 Harmonic Attenuation Module

The ABB 086369-001 is a 5A passive harmonic attenuation module designed for sensitive control systems. Suppressing 3rd-25th order harmonics under a 120/230V framework, this genuine 086369-001 unit eliminates critical system power line noise.

Inquiry stage

Send me part number & company name & whatsapp & email address
Payment stage

Once price confirmed , I will make ProForma Invoice with bank account for you to pay
Shipment stage

Order your parts and arrange collection on the same day from our warehouse, either in person or by courier.

WhatsApp:+86 17359287459

Email:sales15@amikon.cn

Add:Siming district , Xiamen , Fujian,China

Product Introduction

The ABB 086369-001 is a highly specialized passive LC filtering circuit board designed to suppress power grid distortion and optimize power quality. Operating as a compact inline filter, it is strategically deployed between local power sources and sensitive control cabinets to suppress low-order line harmonics ranging from the 3rd up to the 25th order. By mitigating harmonic storms and voltage wave deformations, the module prevents transformer overheating, protects capacitor banks, and ensures that delicate backplane computing electronics receive clean, stabilized power. The board features a space-saving design with built-in surge suppression, visual status LEDs, and a thermal trip safeguard to maximize system uptime.

Ø Nominal Continuous Rated Current: 5 A continuous at 50/60 Hz

Ø Rated Voltage Input: 120 V AC / 230 V AC

Ø Nominal Core Output Voltage: 42 V AC

Ø Harmonic Suppression Efficiency: Typical reduction ≥50% specifically at the 5th harmonic

Ø Fundamental Insertion Loss: < 3% under standard fundamental frequencies

Ø System Frequency Response Range: 150 Hz to 1.25 kHz

Ø Ambient Operating Temperature: 0°C to +55°C (+32°F to +131°F) continuous cabinet environment rating

Ø Relative Operating Humidity: 5% to 95% (Non-condensing state)

Applications by Industry

² DCS Subrack Power Protection: Installed straight inside heavy power distribution rooms on a standard DIN rail right before the power entrance of an ABB Bailey INFI 90 cabinet rack, filtering out severe grid waveform distortions generated by adjacent multi-megawatt Variable Frequency Drives (VFDs).

² Oil, Gas, & Heavy Petrochemical Refining: Secures data network lines and continuous process controller power inputs from random drops, brownouts, or spikes caused by large fluid pump activations.

² Traditional Power Utilities & Generation Generation Cells: Regulates power input purity for boiler control nodes and turbine monitoring instrumentation arrays where harmonic interference could trip false system alarms.

² Pulp, Paper, & Metallurgical Processing Mills: Protects decentralized industrial computers and remote I/O sub-assemblies on factory floors heavily populated with heavy AC/DC motor drives.
