1MRK000173 / 1MRK000005-396 / 1MRK000173-BC Binary I/O Module

Binary input and output interface module for documented ABB Relion protection and control IEDs.

Product overviewConnects field status and control circuits to the relay platform, with voltage range, channel mapping and hardware revision verified before replacement.

CONDITION

New Original

WARRANTY

One year

DIRECT CALL

+86 17359287459

sales9@apterpower.com

Explore other ABB products →

02 / FIRMWARE, UPDATES & APPLICATION PLANNING

Firmware & Updates

IED BASELINE

Record the Relion firmware and PCM600 project version associated with the installed module.

NO SEPARATE LOAD

The I/O board is detected and configured through the host IED rather than a standalone firmware package.

MAPPING BACKUP

Export binary input, output, interlocking and signal-matrix assignments before hardware service.

Application Scenarios

BREAKER CONTROL

Interface trip, close and indication circuits in documented substation protection schemes.

STATUS ACQUISITION

Collect isolator, disconnector and breaker position signals for the protection IED.

IED RETROFIT

Replace a revision-matched internal module while preserving rack and terminal mapping.

Technical data

MODULE TYPE Binary I/O module	PLATFORM Relion 670 / 650	BINARY INPUTS 8 channels
BINARY OUTPUTS 10 + 2 channels	INPUT RANGE 110-125VDC	ISOLATION 2.5kVAC, 1 minute
OPERATE TIME Below 10ms	DIAGNOSTICS IED self-monitoring	MOUNTING Internal keyed slot

Technical values apply to the exact documented revision. Verify the installed board marking, firmware baseline and receiving system before commissioning.
