PRODUCT DETAILS

ABB POWER CONVERSION

MEDIUM-VOLTAGE POWER SWITCHING

ABB 3BHB012961R0001 5SHX 2645L0002
High-Power IGCT

Integrated gate-commutated thyristor module for high-power converter and drive applications.

SYSTEM ROLE

High-Power IGCT

High-Power IGCT provides the main operating function within the ABB power conversion architecture.

Product snapshot

This ABB IGCT combines a press-pack power semiconductor with its associated gate-drive assembly for fast high-current switching in demanding medium-voltage conversion equipment.

System fit

Confirm the complete ABB material code, voltage and current class, gate-unit interface, cooling arrangement, clamping force and converter position before installation.

CONDITION

New Original

WARRANTY

One year

DIRECT CALL

+86 17359287459

sales9@apterpower.com

Explore other ABB products →

PERFORMANCE, EFFICIENCY & APPLICATIONS

TECHNICAL OVERVIEW

OPERATING PROFILE

High-Power IGCT for ABB power conversion

Technical data below is separated from the product overview and excludes shipping weight and package dimensions.

Performance & Efficiency

Low conduction and switching losses support efficient high-power conversion, while the fast gate-commutated structure enables snubberless operation in suitable converter topologies. Correct thermal contact and gate-unit coordination are essential for reliable operation.

Application Scenarios

Used in medium-voltage drives, traction converters, wind-power converters, SVC/STATCOM systems, induction heating and other multi-megawatt power-conversion equipment requiring high current and blocking capability.

Technical data

Device type

Integrated gate-commutated thyristor

Voltage class

4.5kV

Current class

2.6kA

Switching range

Typically 0.2–2kHz

Cooling

Double-sided heatsink conduction

Gate interface

Fiber-optic trigger and status

Application class

High-power conversion

Package

Press-pack IGCT assembly

Verify the complete order identity, hardware revision, electrical interface and installed-system configuration before commissioning.
