PRODUCT PROFILE

ALLEN-BRADLEY · INDUSTRIAL CONTROL

ALLEN-BRADLEY

1771-OG

8-Point TTL Output Module

SYSTEM CONTEXT

PLC-5 1771 I/O Platform

Delivers low-voltage TTL-level discrete outputs to compatible electronic loads.

PRODUCT OVERVIEW

Chassis-mounted TTL output module for established PLC-5 systems. Verify logic convention, external 5V supply, load current and field wiring arm before commissioning.

CONDITION

New Original

WARRANTY

One year

DIRECT CALL

+86 17359287459

sales9@apterpower.com

Explore other Allen-Bradley products →

COMMUNICATION & APPLICATIONS

SYSTEM PLANNING

Communication & Connectivity

Application Scenarios

BACKPLANE COMMANDS

Receives eight discrete output commands through the 1771 chassis backplane.

ELECTRONIC ACTUATION

TTL commands to compatible counters, indicators and control electronics.

TTL LOAD INTERFACE

Drives compatible electronic inputs using selectable high-true or low-true logic.

MACHINE SEQUENCING

Fast low-voltage output switching in legacy automated equipment.

FIELD CONNECTIONS

Retain the specified wiring arm, shield connection and external supply polarity.

CABINET MAINTENANCE

Like-for-like replacement without changing the documented signal scheme.

Technical data

OUTPUT CAPACITY

8 points

HIGH-TRUE ON LEVEL

2.0VDC to 5.25VDC

MAXIMUM SINK CURRENT

20mA per output

OUTPUT DELAY

Less than 1ms

BACKPLANE CURRENT

168mA maximum

ISOLATION TEST

1500VAC RMS
