Inspect each fuse, terminal screw and field conductor when an output circuit is inactive. Confirm the connected output module and field supply before replacing the wiring arm.

De-energize the chassis and field power before service. Replace fuses only with the documented 1.5A type and investigate load faults that caused the original fuse to open.

Label every conductor and retain the original terminal assignment. Check module keying and connector engagement before seating the replacement arm.

Torque terminals correctly, verify insulation condition and test each channel after re-energizing. Confirm that no conductors are pinched by the swing-arm mechanism.

Allen-Bradley 1771 wiring hardware supports durable field termination, channel-level protection and serviceable PLC-5 installations.

PLC-5 output cabinets, relay and solenoid wiring, motor-control centers, process plants, line retrofits and fused field-circuit maintenance.

Send the complete order code, required quantity and delivery destination. Availability, condition, lead time and shipping details will be checked before quotation.
