DISTRIBUTED I/O PROFILE

CALL +86 17359287459 EMAIL sales9@apterpower.com

ALLEN-BRADLEY · FLEX I/O-XT

ARTICLE NUMBER

1794-OB16PXT

OFFICIAL PRODUCT NAME

FLEX I/O-XT 16-Point Output Module

16 OUTPUTS

24 VDC

PROTECTED

CONDITIONNew Original

WARRANTYOne year

AVAILABILITYIn stock

ALLEN-BRADLEY FLEX I/O-XT · EXTENDED-TEMPERATURE OUTPUT HARDWARE

TECHNICAL & OPERATING GUIDE

CALL +86 17359287459 EMAIL sales9@apterpower.com

TECHNICAL SPECIFICATIONS

Output-module identification and electrical details

FLEX I/O-XT OUTPUT HARDWARE

Manufacturer

Allen-Bradley

Article number

1794-OB16PXT

Product type

Protected source output

System family

FLEX I/O-XT

Output points

16 non-isolated

Output voltage

10 to 31.2 VDC

Channel current

0.5 A maximum

Module current

8 A maximum

Flexbus current

60 mA

Supply current

35 mA at 24 VDC

Status indicators

16 yellow LEDs

Terminal bases

1794-TB2 / TB3 / TB3S

OPERATING ENVIRONMENT

Install the module on a compatible FLEX I/O terminal base inside an industrial enclosure. Maintain the documented -20 to +70 C range, protect field wiring from noise and moisture, and isolate field and FLEXBUS power before insertion or removal.

LOCATIONIndustrial control enclosure

TEMPERATURE-20 to +70 C

PROTECTIONIP20 module / protected cabinet

TERMINAL MATCH

FIELD FUSING

POWER ISOLATION

MONITORING & CONTROL

The module provides logic-driven indication for all 16 source outputs and electronic output protection. Commissioning should confirm FLEXBUS recognition, field supply voltage, channel status, load current and stable operation under commanded output changes.

FLEXBUS STATUSConfirm adapter and rack recognition

CHANNEL STATEReview all 16 output indicators

FIELD SUPPLYVerify 10 to 31.2 VDC

LOAD RESPONSECheck protected source outputs

MATCH BASE → SEAT MODULE → APPLY POWER → TEST OUTPUTS
