Input voltage range: Startup mode: 18–30 VDC; Run mode: 12–30 VDC

Input power: 60 W maximum (full load)

Output power: 40 W maximum

Output voltage: +5.1 VDC (30 W maximum); +3.3 VDC (30 W maximum); +24 VDC (for relay module)

Output current: +5.1 VDC: 0–6 A; +3.3 VDC: 0–9 A

Inrush current: 4 A maximum, duration not exceeding 100 ms

Output ripple and noise: 50 mV maximum

Input terminals: Accepts 14–18 AWG cables, 6 A maximum current

Shipping

We will ship the items within 3 working days after the payment is reached.

Cost-effective Solution

We offers competitive pricing and can often provide cost savings compared to original manufacturers, especially for discontinued parts.

Quality Assurance

We emphasize quality testing and have extensive QA processes to ensure the reliability of the parts we sell, often including a 12-month warranty on brand new parts.
