Contact Type: Reed/Magnetic Contact

Switch Type:

NC (Normally Closed): Opens when airflow is present; closes when airflow is lost, used for alarm triggering.

NO (Normally Open): Closes when airflow is present; opens when airflow is not present, used to indicate normal fan operation.

Maximum Switching Voltage: NC supports 240 V (AC/DC), NO supports 60 V DC.

Maximum Switching Current: NC 500 mA (DC), NO 170 mA (DC).

Maximum Switching Power: 10 W (resistive load).

Airflow Trigger Threshold: >2.5 m/s (approximately 8.2 ft/s), with approximately 1 m/s hysteresis.

Maximum Airflow Velocity: 50 m/s (~165 ft/s).

Contact Resistance: Less than 370 mΩ (including wire).

Lifespan: Over 100,000 switching cycles.
