SIEMENS · SIMATIC HMI TP170B

6AV6545-0BB15-2AX0

TP170B Mono Touch Panel

PRODUCT IDENTITY

Siemens 6AV6545-0BB15-2AX0 is a 5.7-inch SIMATIC TP170B monochrome touch panel for local operator control and visualization.

CONDITION

New Original

WARRANTY

One year

AVAILABILITY

In stock · 2

OFFICIAL DATA SOURCE

Siemens technical data sheet for SIMATIC TP170B.

SPECIFICATIONS

OFFICIAL PRODUCT DATA

Configuration and compatibility

PRODUCT DESCRIPTION

The TP170B mono provides machine-level visualization through a resistive touch interface and a 320 × 240 STN display. Its MPI/PROFIBUS DP, serial printer and compact-flash connectivity support established SIMATIC HMI installations configured with ProTool/Lite.

SYSTEM COMPATIBILITY

◆ SIMATIC HMI installations

◆ MPI / PROFIBUS DP

◆ Serial printer connection

◆ CompactFlash memory card

OFFICIAL TECHNICAL DATA

Display

5.7 in STN, monochrome blue

Resolution

320 × 240 pixels

Supply voltage

24 V DC (18–30 V DC)

Rated current

0.25 A

Power consumption

6 W

Processor

32-bit RISC, 66 MHz

Usable memory

768 KB

Interfaces

MPI/DP, RS232, RS422, RS485

Front protection

IP65

Operating temperature

0 to 50 °C vertical

RECOMMAND

APPLICATION GUIDANCE

Service context and related models

DIAGNOSTICS & PROTECTION

Integrated system messages and interface status simplify fault tracing during HMI commissioning and service.

OPERATING ENVIRONMENT

Suitable for cabinet-front operation; observe the official temperature limits for vertical or inclined mounting.

A clear path from identification to dispatch

Identify

Confirm the complete model and installed configuration.

Verify

Check revision, condition and compatibility details.

Quote

Provide availability, commercial terms and lead time.

Dispatch

Pack securely and arrange traceable shipment.
