SIEMENS · PRODUCT DETAILS

Condition · New OriginalWarranty · One year

6ES7131-4BD01-0AB0

SIMATIC DP ET 200S 4DI High Feature 24 V DC Module

PRODUCT SNAPSHOT

This four-channel High Feature module brings parameterizable input acquisition and sensor-circuit diagnostics to compact ET 200S stations. It combines long permitted field-cable runs with channel status indication for reliable service in distributed machine and plant panels.

QUICK CONTACT

☎ +86 17359287459 ✉ sales9@apterpower.com

Explore Siemens →

SIGNAL PATH · OPERATING VALUE

Field communication and efficient signal acquisition

COMMUNICATION & CONNECTION

PERFORMANCE & EFFICIENCY

Station busInput states and diagnostics are exchanged through the ET 200S backplane.

Input currentSignal-1 current is typically 8 mA per active input.

Sensor interfaceFour 24 V DC inputs accept compatible two-wire sensors.

Fast response optionMinimum configurable input delay is 0.1 ms.

Delay settingsFour selectable delay values adapt signal filtering to the application.

Diagnostic visibilityShort-circuit diagnostics and per-channel LEDs aid fault isolation.

Field wiring reachDocumented cable lengths support remote sensor installation.

Electrical separationField channels are isolated from the backplane bus.

OFFICIAL TECHNICAL DATA

Digital inputs4

Rated input voltage24 V DC

Signal-0 range-30 to +5 V

Signal-1 range+11 to +30 V

Signal-1 currentTypical 8 mA

Configurable delay0.1 / 0.5 / 3 / 15 ms

Input characteristicIEC 61131 Type 1

Two-wire sensor supportYes

Sensor quiescent currentMaximum 1.5 mA

Shielded cable lengthMaximum 1000 m

Unshielded cable lengthMaximum 600 m

Isolation test voltage500 V DC

Technical content is based on the Siemens Industry Mall and official Siemens data sheet for 6ES7131-4BD01-0AB0.

BRAND FOUNDATION · FIELD USE

Siemens engineering strengths and application fit

Siemens brand characteristics

Application fields

High Feature ET 200S modules combine dense I/O with configurable diagnostics.

Fast digital sensor acquisition.

Standardized STEP 7 parameters support reproducible station engineering.

Long-cable input circuits in distributed panels.

Channel LEDs and SF indication shorten commissioning feedback loops.

Machine diagnostics and condition signals.

Documented electrical limits support auditable industrial design.

Replacement in established ET 200S High Feature stations.
