Siemens 6ES7135-4LB01-0AB0 ET 200S Analog Output Module

High-feature analog output module for precise voltage control in distributed SIMATIC ET 200S stations.

CONDITIONNew Original

WARRANTYOne year

☎ +86 17359287459 ✉ sales9@apterpower.com

SYSTEM POSITION

ET 200S · 2AO HF U

Two voltage outputs in a compact 15 mm electronic module for distributed actuator control.

Product snapshot

The module provides two analog voltage outputs for -10 V and 1 to 5 V ranges, supporting precise command signals for industrial actuators.

Its high-feature design includes group-fault indication and documented high-resolution conversion for structured commissioning and maintenance.

Explore other Siemens products →

OPERATING INSIGHT

Detailed product description

Designed for SIMATIC ET 200S distributed I/O, this electronic module converts controller values into two voltage output signals. It supports the documented -10 V and 1 to 5 V ranges and is intended for accurate control of drives, valves and positioning devices. Match the terminal module, wiring and engineering configuration before replacement.

◇ Operating environment

Install on a compatible ET 200S terminal module in the documented station configuration. The 15 mm module format supports compact distributed I/O assemblies; wiring and potential groups must follow the ET 200S manual.

◎ Monitoring & control

A red SF group-fault LED supports fault localization. Output behavior, substitute values and channel operation are supervised through the configured ET 200S station and controller diagnostics.

Official technical data

Outputs
2 analog voltage outputs

Output ranges
-10 V; 1 to 5 V

Resolution
15 bit + sign

Module width
15 mm

Conversion time
1 ms max. per channel

Status
SF group-fault LED

Dimensions
1.5x8.1x5.2cm

Weight
0.046kg

BRAND & APPLICATION

Siemens brand characteristics

Siemens automation hardware uses coordinated controller, distributed I/O and engineering concepts across established industrial systems.

Documented order codes, module data and lifecycle paths support structured servicing and replacement planning.

Application fields

Process control loops using voltage-command actuators.

Machine automation with distributed ET 200S analog outputs.
