SIEMENS · PRODUCT DETAILS

Siemens 6ES7144-5KD00-0BA0 SIMATIC ET 200AL AI 4xU/I/RTD Analog Input Module

Four analog channels for voltage, current, resistance and RTD sensing.

SIMATIC ET 200AL

CONDITIONNew Original

WARRANTYOne year

☎ +86 17359287459 ✉ sales9@apterpower.com

Product snapshot

The ET 200AL module collects four analog measurements through M12 sensor connections.

Its configurable measurement types support distributed field sensing in compatible installations.

System fit

Each channel can be configured for the documented electrical measurement type.

Confirm the configured measurement range and sensor wiring before commissioning.

Explore other Siemens products →

Operation, protection & changeover

Practical checks for SIMATIC ET 200AL installations

◇ Diagnostics & Protection

Configurable channel diagnostics and limit interrupts help identify abnormal process values.

Check M12 connectors, supply and configured measurement mode during fault tracing.

↗ Installation & Upgrades

Mount within the compatible ET 200AL system and preserve channel parameterization.

The equipment manual documents firmware update support; follow the Siemens procedure for the installed system.

Official technical data

Analog inputs4	Resolution16 bit	Signal connectionM12, 5-pole
ProtectionIP65/67	Operating range−30 to 55 °C	Width30 mm
Height159 mm	Depth40 mm	Approx. weight168 g

Source: Siemens technical data for 6ES7144-5KD00-0BA0. Only exact-order-code facts are listed.

Platform context & applications

Siemens brand characteristics

Siemens SIMATIC I/O families provide documented station types for structured industrial automation projects.

SIMATIC ET 200AL provides analog input module functionality within the documented SIMATIC platform.

Maintaining the exact order code and project configuration supports orderly service and replacement.

Application fields

Distributed analog sensing in ET 200AL systems.

Voltage, current, resistance and RTD measurement.

Machine upgrades with documented M12 field wiring.
