01 · PRODUCT DETAILS

SiemensSIMATIC DP · DP/PA Coupler Ex

6ES7157-0AD82-0XA0 SIMATIC DP/PA Coupler Ex Field Device Interface

Siemens 6ES7157-0AD82-0XA0 is an official SIMATIC DP field-device interface for coupling PROFIBUS DP with intrinsically safe PROFIBUS PA segments.

BRANDSiemens

SERIESGateways to PROFIBUS DP

CONDITIONNew Original

WARRANTYOne year

IN STOCK2 pcs

SOURCESiemens DP/PA Coupler datasheet

02 · SPECIFICATIONS

Verified DP/PA coupling and hazardous-area interface

FIELD COUPLERPROFIBUSEX INTERFACE

ManufacturerSiemens

Article number6ES7157-0AD82-0XA0

Device designationDP/PA Coupler Ex [ia]

PA output current110 mA max.

PROFIBUS DP rate45.45 kbaud

PROFIBUS PA rate31.25 kbaud

Supply voltage24 V DC (20.4–28.8 V)

Protection / operationIP20 · -25 to +60°C

PRODUCT DESCRIPTION

The Siemens 6ES7157-0AD82-0XA0 provides a galvanically isolated transition between PROFIBUS DP and IEC 61158-2 fieldbus segments such as PROFIBUS PA.

Positioning: Field-device bus coupler for process automation installations that require an Ex [ia] PA segment.

Suffix: 0AD82 identifies the Ex [ia], 110 mA coupler configuration; the full article number is required for exact replacement.

System: Connects PROFIBUS DP upstream to a PROFIBUS PA fieldbus segment and is supplied from 24 V DC.

FEATUREIntrinsically safe PAEx [ia] interface supports hazardous-area fieldbus segments.

FEATUREDual bus conversionCouples PROFIBUS DP communication to PROFIBUS PA.

FEATUREWide environment rangeOfficial data supports -25°C to +60°C operation.

03 · RECOMMEND

Applications and balanced model references

Process instrumentationLinks PA transmitters and field devices to PROFIBUS DP.

Hazardous areasSupports intrinsically safe fieldbus segments.

Plant modernizationMaintains installed DP/PA automation architectures.

Distributed controlConnects remote process instruments to higher-level control.
