PRODUCT PASSPORT · 01

SIEMENS / SIMATIC AFD8

6ES7157-0AG82-0XA0

AFD8 Active Field Distributor

Active field distributor for organizing instrument connections in process fieldbus installations.

AFD
8

Eight-spur fieldbus distributor

BRAND

Siemens

SERIES

SIMATIC AFD8

OFFICIAL NAME

AFD8 Active Field Distributor

SOURCE

Siemens AFD8 Manual

CONDITIONNew Original

WARRANTYOne year

IN STOCK1 pcs

TECHNICAL CIRCUIT · SYSTEM MAP

Eight protected fieldbus spurs from one active distributor

AFD8 distributes PROFIBUS PA or FOUNDATION Fieldbus H1 segments while maintaining automatic termination and spur fault isolation.

COMPLETE MODEL

6ES7157-0AG82-0XA0

ORDERING CODE NOTE

The complete article number defines the AFD8 field distributor with eight short-circuit-proof spur connections.

VERIFIED DATA

Fieldbus

PROFIBUS PA / FF H1

Spur connections

Spur protection

Short-circuit-proof

Supply

Bus-powered

Rated voltage

16–32 V DC

No-load current

34 mA

Power loss

4.1 W maximum

Protection

IP66

SIGNAL ROUTE

Fieldbus trunk

AFD8

Eight spurs

Field instruments

Spur isolation

Short circuits remain confined to one branch.

Auto termination

Supports line and ring topologies.

Outdoor protection

IP66 enclosure for field installation.

03 / FIELD DIRECTORY

Applications

Process fieldbus

Eight-device segment distribution.

Ring topology

Automatic bus termination.

Field installation

Protected industrial junction point.
