PRODUCT DETAILS

6ES7352-5AH00-0AE0

SIMATIC S7-300 FM 352-5 High-Speed Boolean Processor

PRODUCT IDENTITY

Siemens 6ES7352-5AH00-0AE0 SIMATIC S7-300 FM 352-5 High-Speed Boolean Processor

A high-speed S7-300 Boolean processor with 12 digital inputs, 8 current-sinking outputs and an RS422 incremental or SSI encoder interface.

CONDITIONNew Original

WARRANTYOne year

AVAILABILITYIn stock

RELATED MODELS

Specifications

DIAGNOSTICS & PROTECTION

Diagnostic alarms cover missing load supplies, memory-card faults, eight output overloads, encoder-supply overload, differential wire break, parameter errors and SSI frame overflow. The module also provides eight hardware interrupts.

INSTALLATION & UPGRADE

Mount the module in an S7-300 rack and wire it through the 40-pin front connector. Configure it with STEP 7 and the FM 352-5 package. Siemens documents operation behind supported IM 153 interface modules in ET 200M; successor 6ES7352-5AH01-0AE0 retains the sinking-output role.

OFFICIAL TECHNICAL DATA

PRODUCT DESIGNATIONFM 352-5

DIGITAL INPUTS12 × 24 V DC

DIGITAL OUTPUTS8 × 24 V DC, current-sinking

ENCODER INTERFACERS422 incremental / SSI / 24 V incremental

PROGRAM CYCLE1 µs

MAXIMUM INPUT FREQUENCY200 kHz

INPUT-OUTPUT RESPONSE1 to 6 µs, signal-dependent

OUTPUT CURRENT5 mA to 0.6 A; rated 0.5 A at 60 °C

SUPPLY VOLTAGE24 V DC

FRONT CONNECTOR40-pin

Recommand

OPERATING ENVIRONMENT

Operating temperature is 0 to +60 °C. Apply the cabinet, spacing and installation conditions of the SIMATIC S7-300 or ET 200M system for the completed assembly.

MONITORING & CONTROL

LAD or FBD programming, Debug and Normal modes, status LEDs and variable-table monitoring support commissioning. The 1 µs program cycle enables high-speed interlocks, encoder logic and independent machine-sequence control.

6ES7352-5AH00-0AE0

Siemens 6ES7352-5AH00-0AE0

6ES7352-5AH00-0AE0 FM 352-5

SIMATIC S7-300

High-Speed Boolean Processor

Siemens FM Module
