PRODUCT DETAILS

SIEMENS

ARTICLE NUMBER

6ES7422-1HH00-0AA0

SIMATIC S7-400 Relay Output Module

An isolated relay-output module for switching industrial AC and DC loads in SIMATIC S7-400 automation systems.

WARRANTYOne year

AVAILABILITYIn stock

TEL+86 17359287459

EMAILsales9@apterpower.com

DIAGNOSTICS, PROTECTION & INSTALLATION

Outputs16 relay outputs	Rated AC voltage230 V	Rated DC voltage60 V	Output current5 A
IsolationYes	Backplane current1 A max.	Power loss4.5 W typ.	Resistive switching10 Hz max.

DIAGNOSTICS & PROTECTION

INSTALLATION & UPGRADES

◆ Channel status is indicated by front LEDs.

◆ Four potential groups support separated load circuits.

◆ External protection is required because outputs are not short-circuit protected.

◆ The manufacturer data lists no diagnostic messages or process alarms.

◆ Install in compatible SIMATIC S7-400 central or expansion racks.

◆ Use the specified S7-400 front connector and documented field wiring.

◆ Isolate the rack and load circuits before module replacement.

◆ Match the complete article number and configured slot parameters during upgrades.

BRAND CHARACTERISTICS & APPLICATION FIELDS

BRAND CHARACTERISTICS	APPLICATION FIELDS
◆ Order-code-specific modules support precise lifecycle replacement.	◆ Machine and plant control cabinets with switched AC or DC loads.
◆ Modular S7-400 architecture supports documented rack expansion.	◆ Contactors, valves, indicators and industrial signaling circuits.
◆ Galvanically isolated channel groups support structured field wiring.	◆ Process skids, utilities and infrastructure automation systems.
◆ Siemens documentation defines electrical limits for retrofit checks.	◆ Maintenance replacement where established wiring must be retained.
