PRODUCT DETAILS

SIEMENS

ARTICLE NUMBER6ES7972-0BA60-0XA0

OFFICIAL PRODUCT NAME

SIMATIC DP PROFIBUS FastConnect Bus Connector

Compact RS485 bus connector for linking PROFIBUS stations at transmission rates up to 12 Mbit/s. The 35° cable outlet, FastConnect insulation-displacement system and switchable terminating resistor support efficient cabinet wiring and service replacement.

WARRANTY

One year

AVAILABILITY

In stock

TEL

+86 17359287459

sales9@apterpower.com

INSTALLATION, UPGRADES & FIRMWARE

TRANSFER RATE9.6 kbit/s–12 Mbit/s

CABLE OUTLET35°

BUS CONNECTION9-pole Sub-D

PG SOCKETNot fitted

INSTALLATION & UPGRADE

FIRMWARE & UPDATES

01Terminate the IE PROFIBUS cable with the FastConnect insulation-displacement system.

PASSIVE DEVICENo firmware, software image or parameter file is stored in the connector.

02Route the cable through the 35° outlet and secure the connector to the 9-pole Sub-D interface.

UPDATE SCOPEMaintenance is mechanical and electrical; there is no firmware update procedure.

03Set the integrated terminating resistor only at the relevant bus segment end.

NETWORK CHECKVerify PROFIBUS address, cable continuity and termination after replacement.

04For upgrade work, match PG-socket requirement, outlet angle and FastConnect cable type before replacement.

SUCCESSOR REVIEWWhen changing revision, confirm the Siemens successor article and connector geometry.

BRAND CHARACTERISTICS & APPLICATION FIELDS

BRAND CHARACTERISTICS

APPLICATION FIELDS

◆ FastConnect termination reduces preparation steps for compatible PROFIBUS cable.

◆ PROFIBUS DP links for SIMATIC controllers and distributed I/O.

◆ Integrated switchable termination supports defined bus-segment endpoints.

◆ Machine and process-control panels with angled cable routing.

◆ Compact 35° outlet helps route cable in constrained cabinet spaces.

◆ Maintenance replacement of installed RS485 bus connectors.

◆ Siemens documentation enables exact article and successor verification.

◆ Spare-parts programs for legacy industrial communication networks.
