SIEMENS · PRODUCT DETAILS

Condition · New OriginalWarranty · One year

6ES7972-0BB12-0XA0

SIMATIC DP PROFIBUS RS485 Bus Connector with PG Receptacle

PRODUCT SNAPSHOT

This SIMATIC DP connector provides a compact 90-degree cable interface for PROFIBUS networks and includes a PG receptacle for commissioning access. An integrated terminating resistor with isolating function supports controlled segment termination and straightforward network service.

QUICK CONTACT

☎ +86 17359287459 ✉ sales9@apterpower.com

Explore Siemens →

SIGNAL PATH · OPERATING VALUE

Field communication and efficient signal acquisition

COMMUNICATION & CONNECTION

PERFORMANCE & EFFICIENCY

Network standardDesigned for PROFIBUS communication using the RS485 physical layer.

Segment terminationBuilt-in terminating resistor supports correct bus-end configuration.

Transmission rateSupports PROFIBUS data rates up to 12 Mbit/s.

Isolation functionTermination includes an isolating function for defined segment handling.

Programming accessIntegrated PG receptacle permits service connection at the bus plug.

Compact installationNarrow connector geometry suits dense controller interfaces.

Cable routingA 90-degree outlet directs the bus cable along the device face.

Service efficiencyCombined bus and PG access reduces reconnection during diagnostics.

OFFICIAL TECHNICAL DATA

Product typeRS485 bus connector

NetworkPROFIBUS DP

Maximum data rate12 Mbit/s

Cable outlet90 degrees

PG receptacleIntegrated

Terminating resistorIntegrated

Isolating functionYes

Quantity unit1 piece

Technical content is based on the Siemens Industry Mall and official Siemens data sheet for 6ES7972-0BB12-0XA0.

BRAND FOUNDATION · FIELD USE

Siemens engineering strengths and application fit

Siemens brand characteristics

Application fields

Established PROFIBUS components provide predictable SIMATIC network integration.

PROFIBUS connections on SIMATIC controllers.

Documented termination functions support reliable segment commissioning.

Commissioning access through a PG receptacle.

Broad installed-base compatibility simplifies industrial service planning.

Machine and process network segment termination.

Siemens connection accessories use standardized mechanical interfaces.

Replacement of 90-degree RS485 bus plugs.
