PRODUCT DETAILS · SIEMENS SIMATIC NET PROFIBUS OLM

6GK1503-3CA01

OLM/P12 V4.1 Optical Link Module

PRODUCT IDENTITY

Siemens 6GK1503-3CA01 PROFIBUS OLM/P12 V4.1 Optical Link Module converts an electrical RS485 PROFIBUS segment to two plastic or PCF fiber-optic channels for line, star or redundant-ring networks.

CONDITION

New Original

WARRANTY

One year

AVAILABILITY

In stock

RELATED MODELS

SPECIFICATIONS · OFFICIAL PRODUCT DATA

Signal performance and compliance

PRODUCT DESCRIPTION

The OLM/P12 V4.1 provides bidirectional conversion between an electrical RS485 PROFIBUS segment and two plastic or PCF fiber channels. Four BFOC sockets support line, star and redundant optical-ring topologies, while per-channel optical-level test outputs, multicolor status LEDs and a floating group-fault relay assist commissioning and maintenance.

CERTIFICATIONS & STANDARDS

◆ CE conformity

◆ UL 60950-1 / CSA C22.2 No. 60950-1

◆ EN 61000-6-4 Class A emissions

◆ EN 61000-6-2 industrial immunity

OFFICIAL TECHNICAL DATA

PROFIBUS DATA RATE 9.6 kbit/s–12 Mbit/s	PROFIBUS PA RATE 45.45 kbit/s
NETWORK CONNECTIONS 3 maximum: 1 electrical + 2 optical	ELECTRICAL INTERFACE 9-pin Sub-D RS485
OPTICAL INTERFACES 4 × BFOC on 2 channels	PCF LINK LENGTH Up to 400 m at 200/230 µm
POF LINK LENGTH Up to 80 m at 980/1000 µm	SUPPLY VOLTAGE 24 V DC; 18–32 V DC
CURRENT CONSUMPTION Maximum 0.2 A at 24 V DC	PROPAGATION DELAY 6.5 bit times

RECOMMAND · APPLICATION GUIDANCE

Operational checks and related models

DIAGNOSTICS & PROTECTION

Multicolor LEDs, a floating relay contact and per-channel optical-level measuring outputs support clear local status, grouped-fault signaling and fiber-level checks.

OPERATING ENVIRONMENT

IP40 operation is specified from 0 to 60 °C and up to 95% relative humidity without condensation; mount on a 35 mm DIN rail or wall.
