01PRODUCT PROFILECENTUM VP / FIELD I/O
|
YOKOGAWA
ADV561-P11 S1
High-Density Digital Output Module
|
SYSTEM POSITION
High-density discrete output control for CENTUM VP
Drives large groups of 24 VDC field devices from compatible Yokogawa field control stations with isolated current-sink transistor outputs.
|
02PERFORMANCE & APPLICATIONSEFFICIENCY / USE CASES
Performance & Efficiency
Sixty-four isolated transistor outputs consolidate a high point count in one FIO slot, reducing cabinet space and simplifying coordinated actuator control.
Current-sink outputs support status, pulse-width and time-proportioning functions while retaining documented CENTUM engineering and redundancy practices.
|
Application Scenarios
Suitable for solenoid valves, interposing relays, pilot lights and other 24 VDC loads in process-control cabinets.
Applied where high-density output, fast status response and revision-controlled CENTUM VP or CS 3000 integration are required.
|
Technical data
| Applied voltage |
24 VDC |
Output channels |
64, isolated |
| Load rating |
24 VDC, 100 mA |
Supply range |
20.4–26.4 VDC |
| Output format |
Current sink |
ON voltage |
2 VDC max. |
| Status response |
3 ms or less |
Signal cable |
AKB337 |
Confirm the full suffix, field-load current, external supply and output assignment against Yokogawa project documentation before commissioning.
