Description

The Allen-Bradley 1784-KTXD is a legacy, high-performance dual-channel Communication Interface Card engineered to establish simultaneous, multi-network connections between personal computers and industrial control networks. It is designed to install into a standard 16-bit ISA (Industry Standard Architecture) or EISA expansion slot on a computer motherboard. The primary architectural advantage of the 1784-KTXD over the standard KTX card is its dual independent channel capability, which is routed through a single 9-pin D-shell connector using a specialized split-Y cable. Featuring its own onboard microprocessor, the card processes communication tasks independently to prevent taxing the host computer’s CPU. This dual-port design allows a single PC to run software programming, configure nodes, and drive heavy HMI/MMI telemetry data pipelines across two separate Data Highway Plus (DH+) networks or Remote I/O (RIO) links at the same time.

Product info

(1) Core Functionality: Dual-channel Data Highway Plus (DH+) / Remote I/O (RIO) PC Network Interface Card (NIC).

(2) Motherboard Interface: Engineered strictly for standard 16-bit ISA or EISA-compatible expansion slots.

(3) Physical Interface Connector: Features one 9-pin D-shell (DB9) female subminiature serial connection port on its external mounting bracket (requires a split-Y breakout cable for dual network access).

(4) Operating Current Requirements: Rated for a maximum current load of approximately 1.5Amps over a stable + 5.0V DC system circuit.

(5) Hardware Configurations: Utilizes onboard hardware DIP switches (Dual In-line Package) to set up base memory addresses and individual station network addresses.
