01PRODUCT OVERVIEWPROCONTIC T300 / ANALOG I/O
|
ABB
35AA92C GJR5143000R0002
Procontic Analog Output Module
|
PRODUCT ROLE
Analog output interface for documented Procontic control racks
Converts controller output data into field-level analog signals for compatible ABB Procontic installations.
|
02DIAGNOSTICS & DEPLOYMENTPROTECTION / INSTALLATION
Diagnostics & Protection
Compare channel command values, field measurements and controller diagnostics before removal. Check loads and external loops independently.
De-energize field circuits as required, apply ESD controls and verify isolation. Do not bridge channel protection during troubleshooting.
|
Installation & Upgrades
Match the Procontic rack position, board code, terminal assignment and output range. Seat the card evenly and restore shielding.
Preserve channel scaling and engineering units. Validate each analog loop with a controlled output test before process release.
|
Technical data
| Supply range |
12–48 VDC |
Accuracy |
±1% full scale |
| Load range |
0–1 kΩ |
Response time |
≤5 ms |
| Ambient range |
-25°C to +60°C |
Protection class |
IP20 |
| Mounting |
Rack plug-in |
System family |
Procontic T300 |
Verify the complete order code, installed revision and system documentation before commissioning.
03BRAND & APPLICATIONSSYSTEM CONTEXT
| Brand characteristics |
Application fields |
| ABB engineering |
ABB industrial hardware supports dependable operation in established automation systems. |
Process plants |
Analog control of valves, drives and actuators. |
| Installed-base fit |
Procontic modular I/O supports controlled analog-loop maintenance in established automation racks. |
Utilities |
Setpoint output for pumps and treatment equipment. |
| Service discipline |
Documented diagnostics, safe handling and configuration checks support controlled fault recovery. |
Metals |
Mill and furnace auxiliary analog control. |
| Lifecycle continuity |
Complete order-code and revision verification helps preserve the installed system architecture. |
Maintenance |
Like-for-like restoration of Procontic I/O channels. |
