01 / PRODUCT DETAILSACV 700 / OPTICAL LINK

ABB

YPC111B

Optical Distributor Board

PRODUCT OVERVIEW

Optical-channel expansion for ABB drive communication systems

The YPC111B distributes optical communication paths in ABB drive installations where more channels are required than a single short-distance bus interface can provide.

PRODUCT ROLE

Expands optical signal distribution between drive control components.

SYSTEM FIT

Match the board revision, external 24VDC supply and fiber-channel topology.

CONDITION

New Original

WARRANTY

One year

DIRECT CALL+86 17359287459 EMAILsales9@apterpower.com

Explore other ABB products →

02 / DIAGNOSTICS & INSTALLATION

Diagnostics & Protection

Check the 24VDC supply, optical transmitter/receiver activity and fiber routing before replacing the distributor. Clean connectors and verify that transmit and receive fibers are not crossed.

Installation & Upgrades

Mount in the documented enclosure, provide the specified external supply and reproduce the existing fiber map. Verify every optical channel pair with the connected drive equipment.

Technical data

Supply voltage24VDC external

Power consumption2.9VA

Supply current120mA at 24VDC

Channel functionOptical signal distribution

Host interfaceShort Distance Bus

Electrical sideRS-485-based SDB

Fiber arrangementMultiple optical pairs

System familyABB ACV 700
