Functional Description

The Allen-Bradley 1769-IM12 is a 12-point digital input module designed for the CompactLogix and MicroLogix 1500 control systems. The slice-type hardware assembly features 12 independent, high-voltage input channels grouped into distinct hardware circuits to facilitate mixed wiring paths across industrial machinery. The module features optical isolation for noise immunity, a removable terminal block for easy wiring and maintenance, and LED status indicators for each channel. It occupies a single slot and is designed for DIN rail or panel mounting.

(1) Number of Inputs: 12 discrete inputs

(2) Digital Input Type: 240V AC type

(3) Operational Voltage Range: 159V AC to 265V AC

(4) Hardware Filter Latency: Built-in fixed 20 ms standard signal delay

(5) Operating Temperature Range: 0°C to 60°C (32°F to 140°F)

(6) Storage Temperature Range: -40°C to 85°C (-40°F to 185°F)

(7) Relative Humidity Tolerance: Supports up to 95% RH non-condensing relative atmospheric bounds

Applications by Industry

v High-Voltage Control Monitoring: Extensively used to interface with high-voltage AC field instruments like 240V limit switches, physical pushbuttons, and emergency trip stops.

v Motor Control Center Diagnostics: Integrated into motor control centers (MCC) to capture auxiliary contact state responses, thermal overload alarms, and heavy industrial circuit breaker trips.

v Heavy Duty Infrastructure Automations: Deployed across continuous process operations, including water treatment systems, conveyor belts, and manufacturing lines running on standardized 240V AC logic frameworks.
