1772-LP3
PLC-2/30 Processor
| Product snapshot |
A legacy controller processor for executing user programs, coordinating I/O scans and supporting established PLC-2/30 automation systems. |
| 02 |
CERTIFICATIONS, STANDARDS & COMPATIBILITY |
ENGINEERING REVIEW |
|
Certifications & Standards
Use the complete 1772-LP3 catalog identity and the applicable Allen-Bradley PLC-2/30 installation documentation when reviewing conformity. The finished control panel, branch protection, grounding and field wiring determine the standards that apply to the installation.
De-energize the controller before service, retain the specified keyed chassis arrangement and follow site electrical-safety procedures. No undocumented third-party certification is assumed.
|
Compatibility & Interoperability
The processor is intended for an established PLC-2/30 chassis and supports local or remote I/O arrangements documented for the PLC-2 family. Confirm the installed memory module, rack addressing and power configuration before replacement.
Plant-level communication can be provided through the appropriate Allen-Bradley Data Highway adapter. Preserve the existing program, station address, I/O map and network settings before recommissioning.
|
Technical data
| Controller family |
PLC-2/30 |
Input voltage |
120 / 220–240VAC |
| Frequency |
47–63Hz |
Input power |
75VA |
| Memory capacity |
16K words |
I/O capacity |
896 / 1792 points |
Verify the exact order code, installed configuration and applicable project documentation before commissioning.
