A FAQ about 330101-00-25-05-02-05: Why Choose 8 mm Probes
8 mm probes provide a thicker encapsulation of the probe coil in the molded PPS plastic probe tip.
This results in a more rugged probe.
The larger diameter of the probe body also provides a stronger, more robust case.
We recommend that you use 8 mm probes when possible to provide optimal robustness against physical abuse.
The specific parameters 330101-00-25-05-02-05
|
Product type |
3300 XL 8 mm Proximity Probes, Metric |
|
3300 XL 8 mm Probe, 3/8-24 UNF thread, without armor |
|
|
Unthreaded Length |
0.0 in |
|
Overall Case Length |
2.5 in |
|
Total Length |
0.5 meter (1.6 feet) |
|
Connector and Cable-Type |
Miniature coaxial ClickLoc connector, standard cable |
|
Agency Approval |
CSA, ATEX, IECEx Approvals |
Probe Physical Characteristics
The probe tip has a diameter of 8.0 mm (0.31 in). For 3/8-24 threads, the hex size is 9/16 in; for M10 threads, the hex size is M17 (see Note 2).
The case thread features wrench flats: 5/16 in for 3/8-24 threads and 8 mm for M10 threads.
Regarding the cable, the standard 75 Ω cable has a maximum outside diameter of 3.68 mm (0.145 in),
while the FluidLoc cable has a maximum outside diameter of 3.94 mm (0.155 in).
The armor outside diameter is 7.67 mm (0.302 in), and the armor ferrule has a maximum diameter of 9.5 mm (0.38 in).
The miniature male coaxial connector has a maximum outside diameter
|
“D” of 7.24 mm (0.285 in). The unthreaded length is designated |
|
“A”, and the case length is designated |
|
“B”, with a maximum gap of 6.0 mm (0.235 in) between them. The total length |
|
“C” has a tolerance of +30%, -0%. |
