HONEYWELL
900H03-0102
AC Digital Output Module
SYSTEM FAMILY
ControlEdge HC900
CONTROL FUNCTION
Eight-channel AC output module for switching field loads
Honeywell 900H03-0102 eight-channel 120/240V AC digital output module for HC900 controllers.
PRODUCT ROLE
AC Digital Output Module
SYSTEM FIT
Match 120/240V AC loads, fusing and HC900 rack configuration
Firmware & Updates
Output state, failsafe action and control logic are defined by the HC900 project. The module is not loaded with an independent user firmware image during normal service.
Back up the controller database and record slot and channel assignments before removal. De-energize field supplies, verify fusing and complete commanded-load tests after replacement.
Application Scenarios
Switches AC solenoids, contactor coils, alarm devices and other protected plant loads from HC900 controller commands.
Typical installations include burner systems, batch skids, heating equipment and plant auxiliaries requiring grouped AC digital outputs.
Technical data
OUTPUT CHANNELS
8 AC outputs
OUTPUT VOLTAGE
120/240V AC
FREQUENCY
47 to 63Hz
MAX PER CHANNEL
2A
MODULE CURRENT
8A total
OUTPUT DEVICE
Zero-cross triac
CHANNEL FUSE
3.15A time-lag
LOGIC SUPPLY
5V DC, 218mA max
