HONEYWELL
R02S02L03
Analog Output Module
SYSTEM FAMILY
Experion LX
CONTROL FUNCTION
Eight-channel current-output module for precision field control
Honeywell R02S02L03 eight-channel analog output module for compatible Experion LX control systems.
PRODUCT ROLE
Analog Output Module
SYSTEM FIT
Verify rack position, field termination and installed Experion LX revision
Firmware & Updates
Channel engineering, range and fault behavior are maintained in the Experion LX control database. Hardware exchange should use the approved system release and module revision.
Archive the project configuration and record rack, slot and termination details before service. Recommission each loop with controlled output tests and verify controller diagnostics afterward.
Application Scenarios
Provides precise 4–20mA commands to valves, positioners, drives and process instruments in Experion LX applications.
Used in continuous-process units, utilities and packaged automation where multiple analog control loops require coordinated DCS output.
Technical data
OUTPUT CHANNELS
8 single-ended
OUTPUT RANGE
4 to 20mA
RESOLUTION
16 bit
ACCURACY
±0.05% of span
ISOLATION
250V AC
MAXIMUM LOAD
250Ω current loop
OPERATING RANGE
-40 to +70°C
HUMIDITY
5 to 95% non-condensing
Verify the complete product marking, installed-system revision and field configuration before commissioning.
