Product Details

SIMATIC S5 / CP 1430 TCP

2XV9450-1AU00

SIMATIC S5 CP 1430 TCP Communication Processor

Description
Links supported SIMATIC S5 controller families to Industrial Ethernet applications using TCP/IP and ISO-on-TCP services.

WarrantyOne year

AvailabilityIn stock

Related models on Ewolomodule
6GK5308-2GG00-2AA2 6GK7343-1EX11-0XE0 6ES7414-2XG03-0AB0

Specifications / Legacy Industrial Ethernet

CP 1430 TCP official communication profile

Developed for SIMATIC S5 Ethernet communication, this processor supports programmed and parameterized data exchange between established S5 controllers and newer automation stations. Engineering is performed with STEP 5 and the NCM COM 1430 TCP package.

Official technical data

Article number	2XV9450-1AU00	Product designation	CP 1430 TCP
Official software revision	V2.07	Controller families	S5-115U / S5-135U / S5-155U
Network	Industrial Ethernet	Protocols	TCP/IP and ISO-on-TCP (RFC 1006)
Communication service	Active / passive FETCH/WRITE	Engineering	STEP 5 + NCM COM 1430 TCP

Product positioning	Legacy SIMATIC S5 communication processor for Industrial Ethernet and ISO-on-TCP applications.
Suffix meaning	Siemens identifies this configuration by the complete article number; no official segment-by-segment suffix key is published.
System relationship	Works in SIMATIC S5-115U, S5-135U and S5-155U systems; Siemens documents connection to S7-1500 stations through integrated PROFINET or CP 1543-1 Industrial Ethernet interfaces.

Recommand / Application and replacement

Application overview

Legacy control
Industrial Ethernet communication for operating SIMATIC S5 controller installations.

Plant integration
Data exchange between established S5 systems and newer automation stations.

Modernization
Protocol-preserving transition planning for legacy production assets.

Installation

Install in a supported SIMATIC S5 station and engineer the communication processor with STEP 5 and NCM COM 1430 TCP.

Upgrade path

For migration, compare the existing ISO-on-TCP and FETCH/WRITE configuration with a documented S7 communication processor such as CP 343-1 TCP or CP 443-1 TCP.
