SIEMENS · PRODUCT DETAILS

6AV2125-2AE23-0AX0

SIMATIC HMI Mobile Panel Connection Box Advanced

PROFINETPROFIsafeMRP / IRT

PRODUCT SNAPSHOT

An Advanced wall-mounted connection box for SIMATIC HMI Mobile Panels, combining PROFINET and PROFIsafe communication with safety-relay connectivity.

Emergency-stop circuit bridging, terminal detection, an integrated switch, MRP client and IRT support reliable mobile-panel connection in safety-related machine systems.

DIRECT CONTACT

☎ +86 17359287459 ✉ sales9@apterpower.com

DIAGNOSTICS · PROTECTION · COMMISSIONING

Reliable operation with structured installation guidance

◆ Diagnostic protection

Terminal detection identifies the active Mobile Panel connection point.
PROFIsafe supports safety-related communication with compatible control systems.
The integrated switch, MRP client and IRT provide managed real-time network behavior.
Emergency-stop circuit bridging supports controlled safety-circuit continuity.

◆ Installation & upgrade

Mount the Advanced connection box on a suitable wall or machine surface.
Connect PROFINET and PROFIsafe according to the Mobile Panel system design.
Wire the safety relay and emergency-stop circuit to the documented terminals.
Validate terminal detection, MRP and safety functions during commissioning.

OFFICIAL TECHNICAL DATA

Product type
Connection Box Advanced

HMI system
SIMATIC Mobile Panels

Mounting
Wall mounting

Communication
PROFINET and PROFIsafe

Safety connection
Safety relay

Safety feature
Emergency-stop circuit bridging

Network functions
Integrated switch / MRP client / IRT

Detection
Terminal detection

Technical content is based on Siemens documentation for this exact order code. Installation and validation must follow the applicable Siemens manuals.

BRAND STRENGTH · APPLICATION MAP

Industrial integration and application guidance

Siemens brand characteristics

Integrated engineering across controllers, distributed I/O, communication and safety systems.
Documented diagnostics support structured commissioning, maintenance and replacement work.
Long lifecycle support and defined migration paths serve established automation platforms.
Broad industrial portfolio supports machine, process and infrastructure applications.

Application fields

Mobile operator stations on production machinery.
Safety-related HMI connections with PROFIsafe.
Packaging and material-handling equipment.
Machine lines using MRP and real-time PROFINET.
