SIEMENS · PRODUCT DETAILS

6ES7151-1AB02-0AB0

SIMATIC DP IM 151-1 FO Interface Module

PROFIBUS DP12 Mbit/sIntegrated FOC

PRODUCT SNAPSHOT

An IM 151-1 FO interface module that links an ET 200S distributed I/O station to PROFIBUS DP through an integrated fiber-optic interface.

It supports transmission rates up to 12 Mbit/s, an addressing volume of 128 bytes for inputs and outputs, and up to 63 power, electronic or motor-starter modules.

DIRECT CONTACT

☎ +86 17359287459 ✉ sales9@apterpower.com

DIAGNOSTICS · PROTECTION · COMMISSIONING

Reliable operation with structured installation guidance

◆ Diagnostic protection

The fiber-optic interface electrically isolates the fieldbus transmission path.
Module and bus status indications support PROFIBUS DP fault localization.
The interface prepares station data for installed electronic and motor-starter modules.
Defined input and output addressing volumes simplify configuration checks.

◆ Installation & upgrade

Install the interface at the head of an ET 200S station with the supplied termination module.
Connect PROFIBUS DP using the integrated fiber-optic sockets and approved optical cable.
Set the station address and transmission rate to match the master configuration.
For replacement, compare the 128-byte addressing volume with later IM 151-1 FO revisions.

OFFICIAL TECHNICAL DATA

Product type
IM 151-1 FO interface module

I/O system
SIMATIC ET 200S

Fieldbus
PROFIBUS DP

Transmission rate
Up to 12 Mbit/s

Input address volume
128 bytes

Output address volume
128 bytes

Connected modules
Up to 63

Bus interface
Integrated fiber optic

Technical content is based on Siemens documentation for this exact order code. Installation and validation must follow the applicable Siemens manuals.

BRAND STRENGTH · APPLICATION MAP

Industrial integration and application guidance

Siemens brand characteristics

Integrated engineering across controllers, distributed I/O, communication and safety systems.
Documented diagnostics support structured commissioning, maintenance and replacement work.
Long lifecycle support and defined migration paths serve established automation platforms.
Broad industrial portfolio supports machine, process and infrastructure applications.

Application fields

ET 200S distributed I/O on optical PROFIBUS networks.
Electrically isolated fieldbus links in industrial plants.
Motor-starter and remote-I/O station integration.
Service and replacement of legacy IM 151-1 FO stations.
