PRODUCT DETAILS

6ES7174-0AA10-0AA0

SIMATIC S7-300 IM 174 Interface Module

PRODUCT IDENTITY

Siemens 6ES7174-0AA10-0AA0 SIMATIC S7-300 IM 174 Interface Module

A four-axis interface module connecting analog and stepper drives to isochronous PROFIBUS for motion-control systems.

Product series: SIMATIC S7-300 PROFIBUS IM 174

Tel: +86 17359287459

Email: sales9@apterpower.com

RELATED MODELS

SPECIFICATIONS · OFFICIAL PRODUCT DATA

Operating conditions, installation and core data

OPERATING ENVIRONMENT

◆Horizontal mounting permits operation from 0 to 60 °C

◆Vertical mounting has an upper operating limit of 40 °C

◆Install in the S7-300 cabinet with the specified ventilation clearances

INSTALLATION & UPGRADE

◆Mount on the S7-300 rail and tighten the fixing screw to 80–110 N·cm

◆Disconnect power and all encoder, drive and front connectors before replacement

◆Configure the complete module with STEP 7 V5.4 SP4 or later

OFFICIAL TECHNICAL DATA

PRODUCT DESIGNATION

IM 174 interface module

RATED SUPPLY

24 V DC

MODULE CURRENT

Max. 500 mA

BACKPLANE LOAD

5 V DC, max. 100 mA

DRIVE CHANNELS

ENCODER INPUTS

4, incremental or SSI

ANALOG OUTPUTS

4 × ±10 V

PROFIBUS RATE

Up to 12 Mbit/s

RECOMMAND

Safety, efficiency and related models

SAFETY & COMPLIANCE

◆Use protective grounding and equipotential bonding required for S7-300 installations

◆The article is covered by Siemens FM certification for the stated installation conditions

◆RoHS compliance is documented by Siemens from 2008-12-31

PERFORMANCE EFFICIENCY

◆Controls up to four drive axes through one interface module

◆Isochronous PROFIBUS cycle is selectable from 1.5 to 8 ms

◆Four encoder inputs and four ±10 V setpoint outputs centralize multi-axis interfacing
