PRODUCT DETAILS

6GK1151-2AA00

SIMATIC NET CP 1512 Communications Processor

PRODUCT IDENTITY

Siemens 6GK1151-2AA00 SIMATIC NET CP 1512 Communications Processor

A 32-bit CardBus communications processor for connecting a PG or PC to 10/100 Mbit/s Industrial Ethernet.

Product series: SIMATIC NET CP 1512 Industrial Ethernet

Tel: +86 17359287459

Email: sales9@apterpower.com

RELATED MODELS

SPECIFICATIONS · OFFICIAL PRODUCT DATA

Operating conditions, installation and core data

OPERATING ENVIRONMENT

◆Operate from 0 to 60 °C

◆Transport and store from −20 to 70 °C

◆Use at 10–90% relative humidity without condensation

INSTALLATION & UPGRADE

◆Insert in a 32-bit CardBus Type II or III slot

◆Connect the supplied RJ45 adapter and install the matching Siemens driver

◆Verify CardBus and operating-system support before migrating to a newer PC

OFFICIAL TECHNICAL DATA

PRODUCT DESIGNATION

CP 1512 communications processor

NETWORK RATE

10/100 Mbit/s

ETHERNET INTERFACE

RJ45 via supplied adapter

PC INTERFACE

32-bit CardBus, 68-pin

SUPPLY VOLTAGE

3.3 V DC ±5%

MAX. CURRENT

Approx. 0.18 A

PROTOCOLS

ISO, TCP/IP, PROFINET, PG and S7

CARDS PER PC

Maximum 1

RECOMMAND

Safety, efficiency and related models

SAFETY & COMPLIANCE

◆CE conformity is documented for the applicable EMC directive

◆EMC standards include the Siemens-listed residential, light-industrial and industrial environments

◆Install the network cabling according to Siemens Industrial Twisted Pair guidance

PERFORMANCE EFFICIENCY

◆Automatic 10/100 Mbit/s speed detection

◆Full-duplex and half-duplex operation are supported at both data rates

◆Power consumption is 2.0 W according to the Siemens installation guide
