6ES7197-1LB00-0XA0

SIMATIC S7 Y Coupler for Redundant Y-Link

PRODUCT SNAPSHOT

The Siemens 6ES7197-1LB00-0XA0 is a SIMATIC S7 Y coupler used to create a Y-Link between redundant controllers and a subordinate PROFIBUS DP segment. It allows field devices on a shared DP network to remain accessible through the redundant automation-system paths.

The coupler is engineered as part of the complete Y-Link hardware configuration, including compatible interface modules, bus connectors and controller firmware. Proper PROFIBUS addressing, segment timing, grounding and diagnostic handling are essential for dependable high-availability operation.

DIRECT CONTACT

☎ +86 17359287459 ✉ sales9@apterpower.com

RELATED MODELS

COMPLIANCE · LIFECYCLE · ENGINEERING

Certified operation, controlled updates, precise setup

CERTIFICATION & STANDARDS

◆RoHS-compliant since 31 December 2008 according to Siemens product data

◆Integrate within the approved redundant-controller and PROFIBUS system design

◆Observe EMC, grounding and cabinet requirements of the SIMATIC Y-Link documentation

FIRMWARE & UPDATES

◆The coupler is commissioned as part of the Y-Link system rather than with a user program

◆Match interface-module and controller firmware compatibility before changes

◆Back up the redundant hardware configuration before replacing the coupler

CONFIGURATION & PROGRAMMING

◆Insert the Y coupler in the Y-Link hardware configuration for the H system

◆Connect both redundant controller paths and the subordinate DP segment as documented

◆Set PROFIBUS addressing, bus parameters and diagnostic handling in STEP 7

OFFICIAL TECHNICAL DATA

Function Redundant Y-Link coupler	Controller side Redundant SIMATIC system	Fieldbus side PROFIBUS DP	Product status Active
Country of origin Germany	Commodity code 85176200	WEEE take-back Required	SIPLUS variant 6AG1197-1LB00-4XA0

Siemens SiePortal product record for 6ES7197-1LB00-0XA0.

BRAND VALUE · APPLICATION MAP

Engineering strengths and where this model fits

BRAND CHARACTERISTICS	APPLICATION FIELDS
◆Siemens redundancy architecture maintains field access across controller paths	◆SIMATIC S7-400H redundant control systems
◆Standardized Y-Link engineering supports structured PROFIBUS diagnostics	◆High-availability process and production lines
◆Compatible SIMATIC components simplify configuration and lifecycle management	◆PROFIBUS DP field-device integration
◆Documented system behavior supports predictable high-availability maintenance	◆Plant migration and redundancy-expansion projects
