Siemens 6ES7231-5PA30-0XB0 RTD Signal Board

A one-channel 16-bit RTD analog input signal board for Pt100 and Pt1000 temperature measurement on SIMATIC S7-1200 CPUs.

Series

SIMATIC S7-1200

Condition

New Original

Warranty

One year

Availability

In stock

Related models on site

Siemens Products

6ES7132-4BD30-0AA0

6ES7132-6BF00-0BA0

02 · Specifications

Official profile for 6ES7231-5PA30-0XB0

Detailed product description

The SB 1231 RTD signal board adds one resistance-temperature input to a SIMATIC S7-1200 CPU. It supports Pt100, Pt200, Pt500 and Pt1000 sensors, selectable Celsius or Fahrenheit units, and an integrating measurement principle with diagnostic functions.

RTD inputs	1
Resolution	15 bit + sign
Supply	24 V DC
Sensor families	Pt100 / Pt200 / Pt500 / Pt1000

Official technical data

Article number 6ES7231-5PA30-0XB0	Product designation SB 1231, AI 1x16 bit RTD
Power loss 0.5 W typical	Shielded cable 100 m maximum

Operating Environment

Operating temperature	-20 to +60°C
Vertical installation	-20 to +50°C
Storage / transport	-40 to +70°C

Monitoring & Control

Diagnostics	Readable diagnostics supported
Diagnostic alarm	Supported
Wire-break detection	Supported
Status indication	Input and maintenance LEDs

One-channel RTD input

Four platinum sensor types

Integrated diagnostics

03 · Recommand

Application guidance and related products

Brand characteristics

Siemens supports documented automation platforms with coordinated hardware families, official order numbers and structured lifecycle information.

Modular design	Coordinated SIMATIC S7-1200 platform
Documented data	Official product and compatibility records
Service support	Lifecycle documentation for installed systems

Application fields

Process, utility and equipment monitoring.

Machine control	Process, utility and equipment monitoring
Process equipment	Industrial automation and service tasks
System service	Replacement in compatible SIMATIC S7-1200 systems

Installation & upgrade: Fit the signal board to a compatible SIMATIC S7-1200 CPU with power removed, connect the shielded RTD pair and configure the selected sensor type and temperature unit in the engineering software.
