PRODUCT DETAILSSIEMENS

ARTICLE NUMBER

6ES7231-7PB22-0XA8

SIMATIC S7-200 CN RTD Input Module

Two-channel analog input expansion for precise RTD and resistance measurement in compact S7-200 CN automation systems.

WARRANTYOne year

AVAILABILITYIn stock

TEL+86 17359287459

EMAILsales9@apterpower.com

DIAGNOSTICS, PROTECTION & INSTALLATION

Analog inputs2 AI	MeasurementRTD / resistance	Pt sensorsPt100 to Pt10000	Ni sensorsNi100 / 120 / 1000
Cu sensorCu10	Resistance ranges150 / 300 / 600 ohm	Resolution15 bit + sign	Power loss1.8 W

DIAGNOSTICS & PROTECTION

Use the CPU diagnostic buffer and application limits to detect implausible values.
Verify sensor type and measuring range before energizing the channel.
Separate low-level RTD wiring from switching and motor conductors.
Retain the complete article number when sourcing a lifecycle replacement.

INSTALLATION & UPGRADES

Designed only for SIMATIC S7-22X CPU expansion systems.
Configure the EM 231 channel type and range in STEP 7-Micro/WIN.
Use shielded sensor wiring and preserve the documented conductor routing.
Validate both channels after replacement with known reference values.

BRAND CHARACTERISTICS & APPLICATION FIELDS

BRAND CHARACTERISTICS	APPLICATION FIELDS
◆ Siemens order coding identifies the exact S7-200 CN sensor and range variant.	◆ Temperature measurement with platinum, nickel or copper resistance sensors.
◆ Compact expansion architecture supports space-conscious control panels.	◆ Machine utilities and compact process skids using S7-200 controllers.
◆ Official engineering data defines supported RTD and resistance characteristics.	◆ Retrofit support for installed S7-22X automation systems.
◆ Lifecycle replacement is simplified when order code and configuration are retained.	◆ Maintenance replacement where the original measurement range must be preserved.
