PRODUCT DETAILS SIEMENS

ARTICLE NUMBER

6ES7288-5AE01-0AA0

NEW ORIGINAL

PRODUCT IDENTITY

SIMATIC S7-200 SMART Analog Signal Board

This compact signal board extends a compatible SMART CPU with an additional analog measuring point, supporting flexible voltage or current acquisition without a full-width expansion module.

WARRANTY

One year

AVAILABILITY

In stock

TEL

+86 17359287459

sales9@apterpower.com

TECHNICAL PROFILE FIRMWARE · CONFIGURATION

ANALOG INPUTS 1 differential	VOLTAGE RANGES ±10 / ±5 / ±2.5 V	CURRENT RANGE 0–20 mA	VOLTAGE RESOLUTION 11 bit + sign
CURRENT RESOLUTION 11 bit	MAX. RESOLUTION 12 bit	POWER LOSS 0.4 W	INTERNAL CURRENT 50 mA

FIRMWARE & UPDATES

Signal-board operation follows the supported S7-200 SMART CPU firmware and STEP 7-Micro/WIN SMART release.

Back up the CPU project before a firmware update and confirm that the board remains supported by the selected device version.

After service, verify analog scaling and diagnostic status against the documented project baseline.

CONFIGURATION & PROGRAMMING

Select SB AE01 in the CPU signal-board slot using STEP 7-Micro/WIN SMART.

Choose the required voltage or current range and map the single differential channel to the program scaling logic.

Use correct analog grounding and shielding practice, then validate the reading with a known process reference.

BRAND & APPLICATIONS

BRAND CHARACTERISTICS	APPLICATION FIELDS
◆ Signal boards provide space-efficient function expansion directly on compatible S7-200 SMART CPUs.	◆ Adding one analog measurement to compact OEM machine controllers.
◆ Selectable voltage and current ranges support common industrial analog transmitters.	◆ Pressure, level, flow or position acquisition from industrial transmitters.
◆ Micro/WIN SMART keeps device selection, range setup and scaling within one engineering workflow.	◆ Retrofit projects where cabinet space does not allow a full expansion module.
◆ Siemens system documentation coordinates board, CPU firmware and project compatibility.	◆ S7-200 SMART maintenance requiring the original signal-board footprint and configuration.
