Siemens 6ES7422-1BH10-0AA0 Digital Output Module

Industrial digital output module for reliable switching of 24 V DC actuators in modular SIMATIC S7-400 automation systems.

CONDITIONNew Original

WARRANTYOne year

☎ +86 17359287459 ✉ sales9@apterpower.com

SYSTEM POSITION

SIMATIC S7-400 · SM 422

16 isolated outputs arranged in two groups of eight for rack-based actuator control.

Product snapshot

The module switches sixteen 24 V DC load circuits at up to 2 A per output. Grouped galvanic isolation supports clear potential separation inside an S7-400 station.

It is intended for industrial output tasks such as valves, contactors and indicator circuits where the installed rack configuration and field wiring are retained.

Explore other Siemens products →

OPERATING INSIGHT

Detailed product description

Designed for modular S7-400 stations, this SM 422 module converts CPU output commands into sixteen isolated 24 V DC switching channels. Two groups of eight outputs simplify load-potential organization, while the 2 A channel rating supports demanding industrial actuators. The module has no diagnostic interrupt function, so system monitoring should combine the visible channel status with the plant's established electrical protection and maintenance procedures.

◇ Operating environment

Installed in a SIMATIC S7-400 central or expansion rack, with 24 V DC load supply and field wiring selected for the connected actuators. Documented cable limits are up to 600 m unshielded or 1000 m shielded.

◎ Monitoring & control

A green status LED is provided for each channel. The module does not generate diagnostic or process interrupts; operational supervision is therefore handled through channel indication and the control program's process feedback.

Official technical data

Outputs
16 digital outputs

Load rating
24 V DC, 2 A per output

Isolation
2 groups of 8

Output range
5 mA to 2.4 A

Backplane current
160 mA max.

Power loss
5 W typical

Dimensions
2.5x29x21cm

Weight
0.6kg

BRAND & APPLICATION

Siemens brand characteristics

SIMATIC hardware uses coordinated rack, I/O and engineering concepts across established industrial automation systems.

Documented order codes, module data and lifecycle paths support structured servicing and replacement planning.

Application fields

Actuator switching in production lines, process skids, conveyor systems and infrastructure controls.

Lifecycle maintenance and expansion of installed S7-400 systems requiring grouped 24 V DC outputs.
