Siemens 6ES7422-1FH00-0AA0 SIMATIC S7-400 SM 422 16DO AC Digital Output Module

Sixteen AC output channels for S7-400 actuator switching.

SIMATIC S7-400

CONDITIONNew Original

WARRANTYOne year

☎ +86 17359287459 ✉ sales9@apterpower.com

Product snapshot

SM 422 switches 120/230 V AC field loads from a modular S7-400 rack.

It is intended for compatible output circuits where load type and protective design are documented.

System fit

Controller output commands drive connected AC loads through the module.

Check the installed rack, connector and channel grouping before replacement.

Explore other Siemens products →

Operation, protection & changeover

Practical checks for SIMATIC S7-400 installations

◇ Diagnostics & Protection

Review fuse and load-voltage diagnostics alongside the field circuit.

Investigate the load and wiring before assuming a module defect.

↗ Installation & Upgrades

Confirm 120/230 V AC, 2 A output requirements and station slot assignment.

Preserve the project configuration and external protective arrangements.

Official technical data

Digital outputs16	Load voltage120/230 V AC	Output current2 A
Output grouping4 channels per group	Width25 mm	Height290 mm
Depth210 mm	Approx. weight800 g	Resistive switching10 Hz max.

Source: Siemens technical data for 6ES7422-1FH00-0AA0. Only exact-order-code facts are listed.

Platform context & applications

Siemens brand characteristics

Siemens SIMATIC I/O families provide documented station types for structured industrial automation projects.

SIMATIC S7-400 provides digital output module functionality within the documented SIMATIC platform.

Maintaining the exact order code and project configuration supports orderly service and replacement.

Application fields

AC actuator switching in S7-400 cabinets.

Plant control systems with existing SM 422 installations.

Service replacement of documented 16-channel output modules.
