01 / Product Details

Siemens

SIMATIC S7-1500

6ES7511-1AK02-0AB0

CPU 1511-1 PN Central Processing Unit

A controller CPU for machine and plant automation.

ConditionNew Original

WarrantyOne year

In stock3

Official sources

Siemens CPU 1511-1 PN Manual A5E40869673-AB · 05/2021

Specifications

Controller performance & communication

Executes the automation program, exchanges process data with connected I/O and provides integrated diagnostic access.

Program work memory

150 kbyte

Data work memory

1 Mbyte

Typical bit operation

60 ns

Network interface

PROFINET IRT; 2-port RJ45 switch

Rated supply

24 V DC; permitted 19.2–28.8 V

Rated current

0.7 A

Typical power loss

5.7 W

Load memory

SIMATIC Memory Card required

Ordering code

The 1AK02 article identifies this CPU hardware generation. Firmware and engineering-tool requirements must be matched to the installed device.

System connection

STEP 7 V17 supports firmware V2.9; V15 supports firmware V2.5. Use the configuration described in the Siemens equipment manual.

Diagnostics

Integrated status and diagnostic functions support servicing.

Web access

The CPU provides HTTP/HTTPS web-server functions.

Network resilience

MRP is supported on the integrated interface.

Recommand

Explore by application

Machine control

Execution of industrial automation programs.

Plant systems

Connection to distributed I/O and HMI equipment.

Modernization

Reference-matched service of installed S7-1500 systems.
