PRODUCT DETAILS

SIEMENS

ARTICLE NUMBER6ES7972-0BA42-0XA0

OFFICIAL PRODUCT NAME

SIMATIC DP PROFIBUS Bus Connector

Compact PROFIBUS connection plug for transmission rates up to 12 Mbit/s, combining a 35° cable outlet, screw connection and switchable bus termination without a PG socket.

WARRANTY

One year

AVAILABILITY

In stock

TEL

+86 17359287459

sales9@apterpower.com

INSTALLATION, UPGRADES & FIRMWARE

TRANSFER RATEUp to 12 Mbit/s

CABLE OUTLET35°

CABLE CONNECTIONScrew terminals

PG SOCKETNot fitted

INSTALLATION & UPGRADE

FIRMWARE & UPDATES

01Prepare the PROFIBUS cable and land the conductors in the screw terminals.

PASSIVE DEVICEThe connector contains no firmware, software image or parameter file.

02Route the cable through the 35° outlet and secure the plug to the 9-pole interface.

UPDATE SCOPEMaintenance is mechanical and electrical; no firmware update procedure applies.

03Enable the integrated terminating resistor only at the relevant segment end.

NETWORK CHECKConfirm cable polarity, shield continuity and bus termination after service.

04After replacement, verify bus continuity, shielding and station communication.

SUCCESSOR REVIEWMatch outlet angle, screw connection and PG-socket requirement before substitution.

BRAND CHARACTERISTICS & APPLICATION FIELDS

BRAND CHARACTERISTICS

APPLICATION FIELDS

◆ Switchable termination supports clearly defined PROFIBUS segment ends.

◆ PROFIBUS DP links for SIMATIC controllers and distributed I/O.

◆ The compact 35° outlet assists cable routing in control cabinets.

◆ Machine-control cabinets with angled bus-cable routing.

◆ Screw-terminal wiring provides a serviceable field connection.

◆ Maintenance replacement of installed RS485 bus connectors.

◆ Siemens documentation supports exact connector selection.

◆ Legacy industrial communication spare-parts programs.
