Product Details

Motion Control / DRIVE-CLiQ Encoders

6FX2001-5WD13-1AA0

24-bit Singleturn DRIVE-CLiQ Absolute Encoder

Description
Supplies absolute position feedback through a DRIVE-CLiQ interface for motion-control applications.

WarrantyOne year

AvailabilityIn stock

Related models on Ewolomodule
6GK5308-2GG00-2AA2 6GK7343-1EX11-0XE0 6ES7414-2XG03-0AB0

Specifications / Motion feedback

DRIVE-CLiQ absolute encoder official profile

The encoder combines 24-bit singleturn absolute measurement with DRIVE-CLiQ communication. Its hollow-shaft construction and radial M12 connection support direct integration into compatible Siemens drive and motion systems.

Official technical data

Article number	6FX2001-5WD13-1AA0	Resolution	24 bit singleturn
Interface	DRIVE-CLiQ	Operating voltage	24 V DC ±20%
Hollow shaft	12 mm diameter	Maximum cable length	100 m
Degree of protection	IP67 housing / IP64 shaft input	Operating temperature	-30 °C to +100 °C

Product positioning	Absolute position encoder for high-resolution feedback in Siemens motion-control systems.
Suffix meaning	Siemens identifies this configuration by the complete article number; no official segment-by-segment suffix key is published.
System relationship	Connects to compatible DRIVE-CLiQ drive components through a radial M12 connector and provides internal 2048 S/R incremental tracking.

Recommand / Application and replacement

Application overview

Machine tools
Absolute feedback for precision axis and spindle monitoring.

Production lines
Position sensing in automated handling and assembly equipment.

Drive service
Replacement feedback device for compatible DRIVE-CLiQ installations.

Installation

Mount on the matching 12 mm hollow shaft, observe permissible mechanical loads and connect the radial DRIVE-CLiQ M12 interface.

Upgrade path

Verify shaft geometry, connector orientation, DRIVE-CLiQ compatibility and encoder data before replacing an installed feedback device.
