PRODUCT DETAILS

SIEMENS

6GK1161-6AA01

Warranty: One year • Availability: In stock

OFFICIAL PRODUCT NAME

SIMATIC NET CP 1616 PROFINET Communication Processor

Series: SIMATIC NET PC CP / CP 1616

Description: PCI communication processor with an integrated four-port real-time switch for PROFINET IO networking.

RELATED MODELS ON EWOLOMODULE
6ES7407-0RA02-0AA0 6AV2123-2JB03-0AX0 6GK7343-2AH11-0XA0

SPECIFICATIONS / OFFICIAL ENGINEERING DATA

Communication Processor engineering profile

CP 1616 connects PC-based automation systems to PROFINET IO and supports real-time controller and device operation through its integrated Industrial Ethernet switch.

OFFICIAL TECHNICAL DATA

Article number

6GK1161-6AA01

Product type

CP 1616

Host interface

PCI 32-bit, 33/66 MHz

PROFINET ports

4 x RJ45

Transfer rate

100 Mbit/s

Integrated switch

4-port real-time switch

Controller ASIC

ERTEC 400

PROFINET roles

IO Controller / IO Device

Extended diagnostics

Supported from firmware V2.0

Automatic commissioning

Supported from firmware V2.2

MONITORING & CONTROL

Supports extended PROFINET diagnostics and port-status monitoring for PC-based automation systems.

COMMUNICATION & CONNECTION

Provides four 100 Mbit/s RJ45 PROFINET ports and operates as an IO Controller or IO Device.

RECOMMAND

CERTIFICATION STANDARDS

Listed by Siemens as CP 1616 in the applicable RCM supplier declaration; observe the EMC and installation requirements in the operating instructions.

CONFIGURATION & PROGRAMMING

Configure the CP with NCM PC, STEP 7/TIA Portal or the CP 1616 development kit, then assign the PROFINET device name, IP settings and controller/device role.
