PRODUCT DETAILS

6GK1417-5AB00

SIMATIC NET IWLAN/PB Link PN IO Gateway

PRODUCT IDENTITY

Siemens 6GK1417-5AB00 SIMATIC NET IWLAN/PB Link PN IO Gateway

A gateway linking PROFIBUS devices to Industrial Wireless LAN with PROFINET IO proxy functionality.

Product series: SIMATIC NET IWLAN/PB Link PN IO

Tel: +86 17359287459

Email: sales9@apterpower.com

RELATED MODELS

6GK1417-5AB01

6GK1411-5AB00

SPECIFICATIONS · OFFICIAL PRODUCT DATA

Operating conditions, installation and core data

OPERATING ENVIRONMENT

◆Operate from 0 to 60 °C

◆Transport and store from −40 to 70 °C

◆Use up to 2000 m altitude and 95% relative humidity without condensation

INSTALLATION & UPGRADE

◆Configure the gateway in STEP 7 or NCM

◆Use the C-PLUG to retain configuration when replacing the device

◆For migration, Siemens specifies a combined IE/PB Link PN IO and IWLAN Client architecture

OFFICIAL TECHNICAL DATA

PRODUCT DESIGNATION

IWLAN/PB Link PN IO

WLAN STANDARDS

IEEE 802.11a/b/g

IWLAN RATE

1–54 Mbit/s

PROFIBUS RATE

9.6 kbit/s–12 Mbit/s

PROFIBUS PORT

9-pin Sub-D female

ANTENNA PORT

R-SMA

SUPPLY

2 × 24 V DC inputs

SUPPLY RANGE

20.4–28.8 V DC

RECOMMAND

Safety, efficiency and related models

SAFETY & COMPLIANCE

◆Observe the approval marking fitted to the supplied device

◆CE, FCC and country-specific radio approvals depend on the marked regional version

◆Apply the grounding and radio-installation rules in the Siemens device manual

PERFORMANCE EFFICIENCY

◆IWLAN data rate is 1 to 54 Mbit/s

◆PROFIBUS operation supports rates up to 12 Mbit/s

◆Typical power loss is 6.5 W while providing PROFINET IO proxy integration
