PRODUCT DETAILS

6GK5992-2AL00-8AA0

SCALANCE MM992-2 Media Module

PRODUCT IDENTITY

Siemens 6GK5992-2AL00-8AA0 SCALANCE MM992-2 Media Module

A two-port 1000BASE-SX optical media module with SC interfaces for modular SCALANCE industrial switches.

Product series: SCALANCE X-300 MM992 Media Modules

Tel: +86 17359287459

Email: sales9@apterpower.com

RELATED MODELS

SPECIFICATIONS · OFFICIAL PRODUCT DATA

Operating conditions, installation and core data

OPERATING ENVIRONMENT

◆Operate from −40 to 70 °C in a protected industrial enclosure

◆Transport and store from −40 to 85 °C

◆Relative humidity may reach 95% at 25 °C without condensation

INSTALLATION & UPGRADE

◆Insert in a compatible SCALANCE X-300 or XR-300 media-module slot

◆Use SC-terminated multimode glass fiber for the optical links

◆Verify host slot compatibility before replacement; Siemens does not claim hot swapping

OFFICIAL TECHNICAL DATA

PRODUCT DESIGNATION

MM992-2 media module

PORTS

2 optical interfaces

DATA RATE

2 × 1000 Mbit/s

ETHERNET STANDARD

1000BASE-SX

CONNECTOR

FIBER TYPE

Multimode glass

WAVELENGTH

850 nm

MAX. DISTANCE

750 m

RECOMMAND

Safety, efficiency and related models

SAFETY & COMPLIANCE

◆Official declarations document CE, EMC and RoHS conformity

◆Hazardous-location approvals include ATEX, IECEx and FM entries for the stated conditions

◆UL/CSA and BV marine approvals are listed in Siemens certification records

PERFORMANCE EFFICIENCY

◆Two 1000BASE-SX optical ports support redundant or segmented fiber links

◆Multimode transmission distance is up to 750 m

◆Receiver sensitivity is specified down to −17 dBm

6GK5992-2AL00-8AA0 Media Module

Fiber Media Module Datasheet
