Product overview

SIEMENS

Article number

6GK5408-0PA00-8AP2

Warranty: One year
Availability: In stock

Official product name

SCALANCE PE408PoE Port Extender

A modular port extender that adds eight Gigabit RJ45 Power-over-Ethernet ports to a compatible SCALANCE XM-400 managed switch.

Tel : +86 17359287459

Email : sales9@apterpower.com

COMMUNICATION & COMPLIANCE

Eight 10/100/1000 Mbit/s RJ45 ports
Connects as a port extender to a compatible SCALANCE XM-400 switch
An external power supply is required when PoE is used

PoE operation complies with IEEE 802.3at
RoHS-compliant industrial network component
Verify the available PoE budget and use approved industrial cabling

Official technical data

RJ45 ports	8	Transfer rate	10/100/1000 Mbit/s
PoE output per port	30 W max.	Total PoE output	180 W max.
Maximum current	0.2 A	Power loss at 24 V DC	4.8 W
Operating temperature	-40 °C to +60 °C	Degree of protection	IP20

BRAND & APPLICATIONS

Modular SCALANCE port expansion
Eight integrated Gigabit PoE interfaces
Designed for managed XM-400 platforms

PoE cameras and industrial access points
Machine and plant Ethernet expansion
Modular control-cabinet networking
