PRODUCT DETAILS

SIEMENS

7MF0340-1DM01-5AF2-Z

Warranty: One year • Availability: In stock

OFFICIAL PRODUCT NAME

SITRANS P320 Differential Pressure and Flow Transmitter

Series: SITRANS P320

Description: Differential-pressure and flow transmitter with a 4–20 mA HART output and a 60 mbar measuring cell.

RELATED MODELS ON EWOLOMODULE
6ES7407-0RA02-0AA0 6AV2123-2JB03-0AX0 6GK7343-2AH11-0XA0

SPECIFICATIONS / OFFICIAL ENGINEERING DATA

Pressure Transmitter engineering profile

SITRANS P320 converts differential pressure into a HART-enabled 4–20 mA signal for process pressure, level or flow measurement with local display and diagnostics.

OFFICIAL TECHNICAL DATA

Article number

7MF0340-1DM01-5AF2-Z

Product type

SITRANS P320

Output signal

4 to 20 mA HART

Maximum span

60 mbar

Measuring-cell fill

Silicone oil

Process connection

Oval flange

Process material

316L stainless steel

Housing

Die-cast aluminum

Housing design

Dual compartment

Cable entries

2 x M20 x 1.5

MONITORING & CONTROL

The local display and transmitter diagnostics support measurement status, configuration review and process-loop monitoring.

COMMUNICATION & CONNECTION

A two-wire 4–20 mA loop carries the process value, while HART communication provides digital setup and diagnostic access.

RECOMMAND

CERTIFICATION STANDARDS

This non-ex version is documented with worldwide approvals including CE, UKCA, RCM, CSA, EAC, FM and KC markings.

CONFIGURATION & PROGRAMMING

Configure range, damping and linear or square-root characteristic from the local display or through HART with SIMATIC PDM or a compatible host.
