01PRODUCT PROFILECENTUM VP / FIELD I/O
|
YOKOGAWA
ADV142-S02 S1
Isolated AC Digital Input Module
|
SYSTEM POSITION
High-voltage discrete input acquisition for CENTUM VP
Interfaces field-side AC status signals with compatible Yokogawa field control stations while maintaining channel isolation and documented system architecture.
|
02PERFORMANCE & APPLICATIONSEFFICIENCY / USE CASES
Performance & Efficiency
Sixteen isolated AC input channels consolidate high-voltage field status signals in one FIO slot, reducing cabinet footprint and simplifying channel-level fault separation.
Pressure-clamp termination shortens point-to-point wiring, while direct CENTUM integration keeps signal handling inside the documented control-system lifecycle.
|
Application Scenarios
Suitable for breaker status, motor-starter feedback, permissive contacts and other 220–240 VAC discrete signals in continuous-process facilities.
Applied in CENTUM VP and compatible CS 3000 field I/O nodes where exact suffix, terminal arrangement and system revision are maintained.
|
Technical data
| Input signal |
220–240 VAC |
Input channels |
16, isolated |
| Connection |
Pressure-clamp terminal |
Terminal block |
ATC4S |
| Dedicated cable |
AKB333 |
Terminal board |
AEC4D |
| Module current |
500 mA max. at 5 VDC |
Node support |
AFV / ANB FIO nodes |
Confirm the complete suffix, terminal method and installed FCS revision against Yokogawa project documentation before commissioning.
