Description

The 1771-HS3A is a legacy, high-performance three-axis servo controller module designed for closed-loop motion control in demanding factory environments. Operating as an intelligent co-processor within a 1771 I/O chassis, it handles intricate multi-axis synchronization, position, and velocity profiles independently of the primary programmable logic controller's scan cycles. The module supports analog I/O velocity interfaces alongside advanced resolver or encoder physical feedback loops to translate mechanical position changes into highly localized, real-time control metrics. To retain system parameters, downloaded Motion Management Language (MML) programs, and axis profiles during major power failures, it features a plug-in cartridge mechanism utilizing a 1771-HM3A battery-backed CMOS memory module. It integrates a dedicated RS-232 serial interface for connecting configuration terminals or local hand-held pendants, allowing field engineers to adjust active machine coordinates and system variables. Additionally, front-panel LED indicators show operating health and axis tracking faults, providing clear diagnostics directly on the hardware line.

Data informations

l Backplane Power Consumption Load: 1.06 A (Amperes) drawn natively at 5 VDC from the 1771 chassis rail

l Total Synchronized Axis Channels: 3 independent motion axes

l Customer Power Supply Ratings: +5 VDC at 555 mA, +15 VDC at 145 mA, -15 VDC at 94 mA, and +24 VDC at 58 mA

l Physical Module Width: Occupies 1 standard slot in a Bulletin 1771 rack infrastructure

l Operational Ambient Temperature Window: 0°C to 60°C (32°F to 140°F)

l Relative Operational Humidity Tolerances: 5% to 95% non-condensing atmosphere
