The ABB BRC100 BRC-100 P-HC-BRC-10000000 is a high-performance, high-capacity rack-mounted process controller. It serves as a critical interface component within Bailey INFI 90 and Symphony Plus DCS, enabling seamless communication between legacy Harmony I/O racks and modern Symphony Plus control networks. The controller collects process I/O, performs control algorithms, and outputs control signals to process-level devices. It supports multiple control languages, including function codes, C, Basic, Batch 90, and Ladder, and is designed for redundancy to ensure high system availability.

² Supply Voltage: Powered via the system cabinet backplane at a standard nominal rating of 5 VDC.

² Current & Power Consumption: Typically draws a continuous operating current of approximately 2.2 A.

² Station Connectivity: Capable of commanding and connecting directly to up to 128 SAC stations.

² Operating Temperature: Hardened for plant-floor enclosure cabinets, operating reliably from 0°C to 55°C (32°F to 131°F).

² Relative Humidity Windows: Operates smoothly within 5% to 95% non-condensing environments.

Advanced Multi-Loop Control:

DCS Network Bridging:

Critical System Redundancy:

Governs complex analog loops, automated step sequences, and batch processing parameters in continuous chemical and pharmaceutical plants.

Synthesizes and routes field telemetry incoming from Harmony I/O blocks to upper-level enterprise management control levels via Hnet.

Deployed in high-stakes environments where a primary controller failure automatically triggers an instantaneous, bumpless transfer to a backup module to keep operations online.
